Aluminum Hinge 40 Light
Número de producto:
095AL40N0840N08S01
Información sobre el producto "Aluminum Hinge 40 Light"
Assembly Set:
2 countersunk screws DIN 7991 - M6 x 14,
2 self-aligning T-Slot nuts M6 - slot 8
Color:
Cover cap: White aluminum ≈ RAL 9006
Países de Entrega:
En todo el mundo
Description:
For panels and aluminum profiles; left or right side assembly
Material:
Wings: Aluminum
Bolt: Stainless steel
Cover cap: Plastic TPE
Surface:
Wings: Anodized
Bolt: Plain
2 countersunk screws DIN 7991 - M6 x 14,
2 self-aligning T-Slot nuts M6 - slot 8
Color:
Cover cap: White aluminum ≈ RAL 9006
Países de Entrega:
En todo el mundo
Description:
For panels and aluminum profiles; left or right side assembly
Material:
Wings: Aluminum
Bolt: Stainless steel
Cover cap: Plastic TPE
Surface:
Wings: Anodized
Bolt: Plain
| (ECLASS 6.0): | 23219090 |
|---|---|
| (ECLASS 7.0): | 23219090 |
| (ECLASS 8.0): | 23219090 |
| (ECLASS 9.0): | 23219090 |
| (ECLASS 10.0): | 23219090 |
| (ECLASS 11.0): | 23219090 |
| (ECLASS 12.0): | 23219090 |
| (ECLASS 13.0): | 23219090 |
| Cantidad por Paquete: | 10 piezas / 10 jconjuntos |
| Fastening: | Por delante, con tornillos avellanados M6 |
| Model: | Detachable, slot 8 |
| Numero de PA: | 125041 |
| Número de Arancel Aduanero de Exportación: | 83021000 |
| Peso (g): | 106.0 |
| Zolltarifnummer: | 83021000900 |
