Cuarto de Vuelta con Maneta en T 25/18
Número de producto:
0810104
Información sobre el producto "Cuarto de Vuelta con Maneta en T 25/18"
Color:
T-handle insert: Black / -
Housing: Black / -
Seals: Black
Países de Entrega:
North America, Central America, Caribbean, South America, China, United Kingdom, Ireland, Netherlands, Estonia, Latvia, Lithuania,Poland, Czechia, Slovakia, Hungary, Slovenia, Croatia, Serbia, Romania, Bulgaria
Descripción:
For easy and secure latching and locking of doors and flaps;
Wide range of inserts, cams and accessories
Material:
T-handle insert: Plastic PA / zinc die-cast / stainless steel SS316
Housing: Plastic PA / zinc die-cast / stainless steel SS316
Cam: Steel
Seals: Rubber NBR
Nut: Zinc die-cast / stainless steel
Screw: Steel / stainless steel SS316
Especiales:
Keyed different, FH751 key code on request
Superficie:
T-handle insert: Powder coated / plain
Housing: Powder coated / plain
Cam: Zinc plated
Nut: Zinc plated / plain
Screw: Zinc plated / plain
Consejo:
Compatible Cams see 0810247 et sq.
Accessories see 0890032 et sq.
T-handle insert: Black / -
Housing: Black / -
Seals: Black
Países de Entrega:
North America, Central America, Caribbean, South America, China, United Kingdom, Ireland, Netherlands, Estonia, Latvia, Lithuania,Poland, Czechia, Slovakia, Hungary, Slovenia, Croatia, Serbia, Romania, Bulgaria
Descripción:
For easy and secure latching and locking of doors and flaps;
Wide range of inserts, cams and accessories
Material:
T-handle insert: Plastic PA / zinc die-cast / stainless steel SS316
Housing: Plastic PA / zinc die-cast / stainless steel SS316
Cam: Steel
Seals: Rubber NBR
Nut: Zinc die-cast / stainless steel
Screw: Steel / stainless steel SS316
Especiales:
Keyed different, FH751 key code on request
Superficie:
T-handle insert: Powder coated / plain
Housing: Powder coated / plain
Cam: Zinc plated
Nut: Zinc plated / plain
Screw: Zinc plated / plain
Consejo:
Compatible Cams see 0810247 et sq.
Accessories see 0890032 et sq.
| (ECLASS 6.0): | 23199090 |
|---|---|
| (ECLASS 7.0): | 23199090 |
| (ECLASS 8.0): | 23199090 |
| (ECLASS 9.0): | 23199090 |
| (ECLASS 10.0): | 23199090 |
| (ECLASS 11.0): | 23199090 |
| (ECLASS 12.0): | 23199090 |
| (ECLASS 13.0): | 23199090 |
| Cantidad por Paquete: | 10 piezas |
| IP Rating: | IP65 / NEMA 4 |
| Numero de PA: | 121662 |
| Número de Arancel Aduanero de Exportación: | 83024110 |
| Peso (g): | 172.4 |
| Versión de Puerta: | Derecha, izquierda |
