Tool Hook FX 66/27 - 13 for Square Holes 9 x 9 (8.7 x 8.7)
0,00 €
Número de producto:
6TP38A9030ESDS01
Cantidad por Paquete:
1 pieza
Información sobre el producto "Tool Hook FX 66/27 - 13 for Square Holes 9 x 9 (8.7 x 8.7)"
Color:
Rear mounting holder: Black
Front locking holder: Black
Países de Entrega:
En todo el mundo
Description:
Ready to use tool hook, 360° turnable, for perforated metals up to 1.4 mm thick;
To organize workstations, with labeling area for standard labels
Material:
Rear mounting holder ESD electrostatical discharging version: Plastic PA, carbon fiber reinforced
Front locking holder ESD electrostatical discharging: Plastic PA, glass ball reinforced with carbon
Wire: Stainless steel SS304
Spring: Spring steel SS313
Screw: Steel
Nut: Steel
Specials:
Other colors on request,
For other sheet metal thicknesses on request
Surface:
Screw: Zinc plated
Nut: Zinc plated
Tip:
For profiles 40 / 45, slot 8 / 10 see 6TH240NA9030S01
For round tubes D28 / D30 see 6TH2D283A9030EDS1-
Rear mounting holder: Black
Front locking holder: Black
Países de Entrega:
En todo el mundo
Description:
Ready to use tool hook, 360° turnable, for perforated metals up to 1.4 mm thick;
To organize workstations, with labeling area for standard labels
Material:
Rear mounting holder ESD electrostatical discharging version: Plastic PA, carbon fiber reinforced
Front locking holder ESD electrostatical discharging: Plastic PA, glass ball reinforced with carbon
Wire: Stainless steel SS304
Spring: Spring steel SS313
Screw: Steel
Nut: Steel
Specials:
Other colors on request,
For other sheet metal thicknesses on request
Surface:
Screw: Zinc plated
Nut: Zinc plated
Tip:
For profiles 40 / 45, slot 8 / 10 see 6TH240NA9030S01
For round tubes D28 / D30 see 6TH2D283A9030EDS1-
| Model: | Pre-ensamblado |
|---|---|
| Cantidad por Paquete: | 1 pieza |
| Número de Arancel Aduanero de Exportación: | 83025000 |
| Peso (g): | 82.1 |
| (ECLASS 6.0): | 23369290 |
| (ECLASS 7.0): | 23369290 |
| (ECLASS 8.0): | 23369290 |
| (ECLASS 9.0): | 23369290 |
| (ECLASS 10.0): | 23369290 |
| (ECLASS 11.0): | 23360192 |
| (ECLASS 12.0): | 23360192 |
| (ECLASS 13.0): | 23360192 |
| Numero de ERP: | 160962 |
| Zolltarifnummer: | 83025000000 |
