Trolley 40 for Overhead C-Rail, with Mounting Plate

Información sobre el producto "Trolley 40 for Overhead C-Rail, with Mounting Plate"

Países de Entrega:
En todo el mundo

Description:
To build towing trolleys with aluminum profile 40, for hanging cables or lines optional tool hangers can be inserted into the slot of the aluminum profile;
Ball bearing guide of the trolley in the overhead C-monorail

Material:
Trolley: Aluminum die-cast
Ball bearings: Steel

Surface:
Trolley: Plain

Tip:
Compatible Tool Hangers see 093007

Zolltarifnummer:
83022000900
(ECLASS 6.0): 23369290
(ECLASS 7.0): 23369290
(ECLASS 8.0): 23369290
(ECLASS 9.0): 23369290
(ECLASS 10.0): 23369290
(ECLASS 11.0): 23360192
(ECLASS 12.0): 23360192
(ECLASS 13.0): 23360192
Cantidad por Paquete: 10 piezas
Model: Aluminio fundido a presión
Peso (g): 250.0

Variantes

ID de producto D (mm)
093820 8.5
