Spring Style Quarter Turn Lock 22.5 / 13

Informations sur le produit "Spring Style Quarter Turn Lock 22.5 / 13"

Couleur:
Joint : Noir

Pays de livraison:
Amérique du Nord, Amérique centrale, Caraïbes, Amérique du Sud, Chine, Royaume-Uni, Irlande, Pays-Bas, Estonie, Lettonie, Lituanie, Pologne, Tchéquie, Slovaquie, Hongrie, Slovénie, Croatie, Serbie, Roumanie, Bulgarie

Description:
For easy and secure latching and locking of doors and flaps;
Wide range of cams and accessories

Material:
Insert: Stainless steel SS316
Housing: Stainless steel SS316
Cam: Steel
Seal: Rubber NBR
Nut: Stainless steel SS316
Screw: Stainless steel SS316

Surface:
Cam: Zinc plated

Tip:
Compatible Cams see 0810247 et sq.
Accessories see 0890032 et sq.

Zolltarifnummer:
83014090000
(ECLASS 6.0): 23199090
(ECLASS 7.0): 23199090
(ECLASS 8.0): 23199090
(ECLASS 9.0): 23199090
(ECLASS 10.0): 23199090
(ECLASS 11.0): 23199090
(ECLASS 12.0): 23199090
(ECLASS 13.0): 23199090
Conditionnement: 10 pièces
Poids (g): 97.2

Variantes

ID de produit Insert type
0810127ES01 Slotted recess 2 x 4

Téléchargements CAD

Certificats
