Broom Holder FLEX FX 20 - 30 for Tubes D28 / D30

Product information "Broom Holder FLEX FX 20 - 30 for Tubes D28 / D30"

Color:
Holder: Black
Retaining strap: Black

Delivery Countries:
Worldwide

Description:
Ready to use broom holder to hang up tools with Ø 20 up to 30 mm diameter, 360° turnable, for tubes or tubular frame profiles;
To organize workstations

Material:
Broom holder: Plastic PA, glass ball reinforced
Retaining strap FLEX: Plastic TPE
Bushings: Steel
Screws for retaining strap: Steel
Spring: Spring steel SS313
Screw: Steel
Nut: Steel

Specials:
Other colors on request

Surface:
Screw: Zinc plated
Nut: Zinc plated
Pack Quantity: 1 piece
Model: Pre-assembled
Weight (g): 210.2
ERP Number: 160336

Variants

Part # Color CAD
Black

CAD Downloads

Classifications

ECLASS 6.0
23369290
ECLASS 7.0
23369290
ECLASS 8.0
23369290
ECLASS 9.0
23369290
ECLASS 10.0
23369290
ECLASS 11.0
23360192
ECLASS 12.0
23360192
ECLASS 13.0
23360192
Zolltarifnummer
39269097900
Customs Tariff Number Export
39269097

Certificates

Tags

Profile Type Profile Type B, Profile Type I
Modular Dimension Modular Dimension D28, Modular Dimension D30
Profile Form Round Tubular Profiles
Application Area Industrial Work Stations
