ECO Connection Plate AL X 7 Hole, 1 Slot Version

Product information "ECO Connection Plate AL X 7 Hole, 1 Slot Version"

Color:
Black

Delivery Countries:
North America

Description:
To connect two aluminum profiles

Material:
Aluminum

Surface:
Powder coated / anodized

Tip:
Compatible ECO T-nut see 096E20M5S05 et sq.

Zolltarifnummer:
76169990990

Model:	Aluminum
Pack Quantity:	10 pieces
Weight (g):	265.0

Variants

Product ID	Fig.	Color	Surface	A (mm)	L (mm)	H (mm)	K (mm)	Version	B (mm)	ØD (mm)
093EVX114190	②		Anodized	38.1 (1.5")	114.3 (4.5")	6.35 (0.25")	38.0 (1.49")	114 / 190 - 4.4" / 7.5"	190.5 (7.50)	9.0 (0.35")
093EVX114190S	①	Black	Powder coated	38.1 (1.5")	114.3 (4.5")	6.35 (0.25")	38.0 (1.49")	114 / 190 - 4.4" / 7.5"	190.5 (7.50)	9.0 (0.35")
093EVX76127	②		Anodized	25.4 (1")	76.2 (3")	4.8 (0.19")	25.0 (0.98")	76.2 / 127 - 1" / 5"	127 (5")	7.0 (0.27")
093EVX76127S	①	Black	Powder coated	25.4 (1")	76.2 (3")	4.8 (0.19")	25.0 (0.98")	76.2 / 127 - 1" / 5"	127 (5")	7.0 (0.27")
