Fastening Set for Handle AL 200

Product information "Fastening Set for Handle AL 200"

Color:
Black, aluminum color

Delivery Countries:
Worldwide

Description:
For front mounting of the handles AL 200

Material:
Zinc die-cast

Set:
2 fastenings,
2 screws DIN 7991 - M8 x 18

Surface:
Powder coated

Tip:
Compatible Handles AL 200 see 092328 and 092329
(ECLASS 6.0): 23019104
(ECLASS 7.0): 23019190
(ECLASS 8.0): 23019190
(ECLASS 9.0): 23019190
(ECLASS 10.0): 23019190
(ECLASS 11.0): 23010192
(ECLASS 12.0): 23010192
(ECLASS 13.0): 23010192
Model: Zinc die-cast, 200 mm
Pack Quantity: 1 set
Weight (g): 141.0

Variants

Product ID Color Profile
092331 Black I
092336 Alu color I

CAD Downloads

Certificates
