Hygienic Quarter Turn Lock 22.5 / 18

Product information "Hygienic Quarter Turn Lock 22.5 / 18"

Color:
Seal: Black

Delivery Countries:
North America, Central America, Caribbean, South America, China, United Kingdom, Ireland, Netherlands, Estonia, Latvia, Lithuania,Poland, Czechia, Slovakia, Hungary, Slovenia, Croatia, Serbia, Romania, Bulgaria

Description:
For easy and secure latching and locking of doors and flaps;
Wide range of cams and accessories

Material:
Insert: Stainless steel SS316
Housing: Stainless steel SS316
Seal: Rubber NBR
Nut: Stainless steel SS316
Screw: Stainless steel SS316

Tip:
Compatible Cams see 0810247 et sq.
Accessories see 0890032 et sq.

Zolltarifnummer:
83014090000
(ECLASS 6.0): 23199090
(ECLASS 7.0): 23199090
(ECLASS 8.0): 23199090
(ECLASS 9.0): 23199090
(ECLASS 10.0): 23199090
(ECLASS 11.0): 23199090
(ECLASS 12.0): 23199090
(ECLASS 13.0): 23199090
Pack Quantity: 10 pieces
Weight (g): 87.0

Variants

Product ID Insert type
0812150E SW13 Insert

CAD Downloads

Certificates
