Turning Angle 45
Part #:
093WG402N
Product information "Turning Angle 45"
Assembly Set:
2 screws DIN EN ISO 10642 (DIN 7991) - M8 x 18,
2 hammer nuts - slot 10 - M8,
4 Centering bolt slot 8,
4 Centering bolt slot 10
Color:
Turning angle: Alu color
Centering bolts: Black
Delivery Countries:
Worldwide
Description:
To connect aluminum profiles at various angles from 0° to 180°
Material:
Turning Angle: Aluminum die-cast
Centering bolts: Plastic PA, glass fiber reinforced
Assembly set: Steel
Surface:
Turning angle: Plain / powder coated
Assembly set: Zinc plated
Tip:
* With 4 centering bolts slot 8 and 4 centering bolts slot 10
2 screws DIN EN ISO 10642 (DIN 7991) - M8 x 18,
2 hammer nuts - slot 10 - M8,
4 Centering bolt slot 8,
4 Centering bolt slot 10
Color:
Turning angle: Alu color
Centering bolts: Black
Delivery Countries:
Worldwide
Description:
To connect aluminum profiles at various angles from 0° to 180°
Material:
Turning Angle: Aluminum die-cast
Centering bolts: Plastic PA, glass fiber reinforced
Assembly set: Steel
Surface:
Turning angle: Plain / powder coated
Assembly set: Zinc plated
Tip:
* With 4 centering bolts slot 8 and 4 centering bolts slot 10
| (ECLASS 6.0): | 23360290 |
|---|---|
| (ECLASS 7.0): | 23360290 |
| (ECLASS 8.0): | 23360290 |
| (ECLASS 9.0): | 23360290 |
| (ECLASS 10.0): | 23360290 |
| (ECLASS 11.0): | 23360290 |
| (ECLASS 12.0): | 23360290 |
| (ECLASS 13.0): | 23360290 |
| Customs Tariff Number Export: | 76169910 |
| Model: | Aluminum die-cast |
| Pack Quantity: | 10 pieces / 10 set |
| Weight (g): | 45.0 |
| Zolltarifnummer: | 76169910990 |
| pA Number: | 101082 |
Certificates
