Clamping Angle I 30 with Locking Lever, Slot 6

Product information "Clamping Angle I 30 with Locking Lever, Slot 6"

Color:
Alu color

Delivery Countries:
Worldwide

Description:
To connect aluminum profiles easily and with flexibility

Material:
Bracket: Zinc die-cast
KIPP-locking lever: Plastic PA, glass fiber reinforced
Mechanic: Blue-galvanised steel (RoHS conform)

Specials:
Other surfaces, other colors on request

Surface:
Plain / powder coated

Tip:
Other slots on request

Zolltarifnummer:
79070000900
(ECLASS 6.0): 23360290
(ECLASS 7.0): 23360290
(ECLASS 8.0): 23360290
(ECLASS 9.0): 23360290
(ECLASS 10.0): 23360290
(ECLASS 11.0): 23360290
(ECLASS 12.0): 23360290
(ECLASS 13.0): 23360290
Fastening: Using M6 screw
Model: Zinc die-cast
Pack Quantity: 10 pieces
Weight (g): 64.0

Variants

Product ID Profile Slot N (mm) Color Surface
093WKF301N06A I 6 Alu color Powder coated
093WKF301N06R I 6 Plain
