ECO Connection Plate AL Rectangular 3 Hole, 1 Slot Version
Product number:
093EVA2576
Product information "ECO Connection Plate AL Rectangular 3 Hole, 1 Slot Version"
Color:
Black
Delivery Countries:
North America
Description:
To connect two aluminum profiles
Material:
Aluminum
Surface:
Powder coated / anodized
Tip:
Compatible ECO T-nut see 096E20M5S05 et sq.
Zolltarifnummer:
76169990990
Black
Delivery Countries:
North America
Description:
To connect two aluminum profiles
Material:
Aluminum
Surface:
Powder coated / anodized
Tip:
Compatible ECO T-nut see 096E20M5S05 et sq.
Zolltarifnummer:
76169990990
Model: | Aluminum |
---|---|
Pack Quantity: | 10 pieces |
Weight (g): | 20.0 |
Variants
Product ID | Fig. | Version | Color | Surface | ØD (mm) | A (mm) | H (mm) | L (mm) | B (mm) |
---|---|---|---|---|---|---|---|---|---|
093EVA2576 | ② | 38 / 114 - 1.5" / 4.5" | Anodized | 7.0 (0.27") | 25.4 (1") | 4.8 (0.19") | 76.2 (3") | 22.2 (0.88") | |
093EVA2576S | ① | 38 / 114 - 1.5" / 4.5" | Black | Powder coated | 7.0 (0.27") | 25.4 (1") | 4.8 (0.19") | 76.2 (3") | 22.2 (0.88") |
093EVA38114 | ② | 38 / 114 - 1.5" / 4.5" | Anodized | 9.0 (0.35") | 38.1 (1.5") | 6.35 (0.25") | 114.3 (4.5") | 38.0 (1.49") | |
093EVA38114S | ① | 38 / 114 - 1.5" / 4.5" | Black | Powder coated | 9.0 (0.35") | 38.1 (1.5") | 6.35 (0.25") | 114.3 (4.5") | 38.0 (1.49") |
