ECO Connection Plate AL Rectangular 4 Hole, 1 Slot Version

Product information "ECO Connection Plate AL Rectangular 4 Hole, 1 Slot Version"

Color:
Black

Delivery Countries:
North America

Description:
To connect two aluminum profiles

Material:
Aluminum

Surface:
Powder coated / anodized

Tip:
Compatible ECO T-nut see 096E20M5S05 et sq.

Zolltarifnummer:
76169990990
Model: Aluminum
Pack Quantity: 10 pieces
Weight (g): 93.0

Variants

Product ID ØD (mm) A (mm) H (mm) Version L (mm) B (mm) Fig. Color Surface
093EVA25102 7.0 (0.27") 25.4 (1") 4.8 (0.19") 25 / 101 - 1" / 4" 101.6 (4") 22.2 (0.88") Anodized
093EVA25102S 7.0 (0.27") 25.4 (1") 4.8 (0.19") 25 / 101 - 1" / 4" 101.6 (4") 22.2 (0.88") Black Powder coated
093EVA38152 9.0 (0.35") 38.1 (1.5") 6.35 (0.25") 38 / 152 - 1.5" / 6" 152.4 (6") 38.0 (1.49") Anodized
093EVA38152S 9.0 (0.35") 38.1 (1.5") 6.35 (0.25") 38 / 152 - 1.5" / 6" 152.4 (6") 38.0 (1.49") Black Powder coated
