ECO Connection Plate AL T 5 Hole, 1 Slot Version

Product information "ECO Connection Plate AL T 5 Hole, 1 Slot Version"

Color:
Black

Delivery Countries:
North America

Description:
To connect two aluminum profiles

Material:
Aluminum

Surface:
Powder coated / anodized

Pack Quantity:	10 pieces
Model:	Aluminum
Weight (g):	164.0
ERP Number:	150587

Variants

Part #	Version	H (mm)	A (mm)	B (mm)	L (mm)	Fig.	K (mm)	Surface	Color	ØD (mm)
093EVT7676S	76.2 / 76.2 - 3" / 3"	4.8 (0.19")	25.4 (1")	76.2 (3")	76.2 (3")	①	25.4 (1")	Powder coated	Black	7.0 (0.27")
093EVT114114S	114 / 114 - 4.48" / 4.48"	6.35 (0.25")	38.1 (1.5")	114.3 (4.5")	114.3 (4.5")	①	38.0 (1.49")	Powder coated	Black	9.0 (0.35")
093EVT7676	76.2 / 76.2 - 3" / 3"	4.8 (0.19")	25.4 (1")	76.2 (3")	76.2 (3")	②	25.4 (1")	Anodized	-	7.0 (0.27")
093EVT114114	114 / 114 - 4.48" / 4.48"	6.35 (0.25")	38.1 (1.5")	114.3 (4.5")	114.3 (4.5")	②	38.0 (1.49")	Anodized	-	9.0 (0.35")

Classifications

ECLASS 6.0: 23360290
ECLASS 7.0: 23360290
ECLASS 8.0: 23360290
ECLASS 9.0: 23360290
ECLASS 10.0: 23360290
ECLASS 11.0: 23360290
ECLASS 12.0: 23360290
ECLASS 13.0: 23360290
Zolltarifnummer: 76169990990
Customs Tariff Number Export: 76169990

Certificates

RoHS Certificate

REACH Certificate

POP Certificate

Conflict Minerals Certificate

Tags

Product Feature	Fractional
Profile Form	T-slot Profiles
Application Area	Machinery & Plant Engineering
