Fixed Caster Ø 75

Product information "Fixed Caster Ø 75"

Color:
Housing: Alu color
Tread: See table
Wheel body: Gray

Delivery Countries:
Worldwide

Description:
Reliable and quiet swivel caster, trackless, with thread guard; can be directly fixed to aluminum profiles, with optional locating pin slot 8 secured against rotation

Material:
Housing: Steel
Tread: See table
Wheel body: See table
Locating pin: Steel

Specials:
Other kinds of wheels, other colors, other surfaces on request

Surface:
Housing: Powder coated
Locating pin: Zinc plated

Zolltarifnummer:
73269098900
Fastening: For end face mounting, a suitable thread must be cut into the core hole
Model: With bolt hole pattern and separate locating pin for slot 8
Pack Quantity: 1 piece
Weight (g): 273.0

Variants

Product ID H (mm) D (mm) ESD Fixed Caster Tread Max. Load (N) Wheel Body
098F075TN 98 75 PP, gray 700 TPE, gray ≈ RAL 7001
098F075TNESD 98 75 ESD PP, black 490 TPE, gray ≈ RAL 7031
