Slot-on-Slot Connector SOS I8 360°

Description:Power strip with sockets for power supply at workstations; On the backside with slot 8 for mounting on aluminum profilesMaterial:Housing: Aluminum End caps: Plastic PA, carbon fiber reinforced Socket inserts: Plastic PASurface:Housing standard version: Anodized Housing ESD electrostatical discharging version: Powder coatedColor:Housing standard version: - Housing ESD electrostatical discharging version: Black End caps: Black Socket inserts: BlackTip:Compatible LED Lamp see 6SL1040DI.953 Compatible Main Power Cable see 6SAME4J316B.2000 Compatible Connection Cable see 6SACP3J316B.2000 Compatible Connection Coupling see 6SAKP3J316BS01 Compatible Cover Cap for 3 pole female connector see 063SGF3S01 Compatible Direct Connector I, Slot 8 see 099DC084040N08 Compatible Direct Connector I / B, Slot 8 / 10 see 099DC084045N10Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 wattsSpecials:Further colors, individually configurated power strips on requestDelivery Countries:WorldwidePlug type countries:Type F: DE, AT, NL, ES, PT, GR, IS, HR, LV, LT, EE, LU, RU, HU, UA, BY, TR, RS, SI, RO, BG, ID, KR Type G: UK, MY, IE, IQ, AE, KE, KW, HK, MT, MU, MM, NG, OM, SG, QA, VN, CY Type E: FR, BE, CZ, SK, PL, MA, CM, TN

Description:Remote dimmable LED Lamp for power and light supply at work stations; Input side only compatible with power strip Modul F Line with dimmable exit; On the backside with slot 8 for mounting on aluminum profilesMaterial:Housing: Aluminum End caps: Plastic PA, carbon fiber reinforced Diffusing screen: Polycarbonate Dimmer button: Plastic ABS / PASurface:Housing standard version: Anodized Housing ESD electrostatical discharging version: Powder coatedColor:Housing standard version: - Housing ESD electrostatical discharging version: Black End caps: Black Diffusing screen: Transparent (colorless) Dimmer button standard version: Blue Dimmer button ESD electrostatical discharging version: OrangeTip:Compatible Power Strip Module F Line 370 4x, with Switch and Dimmer Button, for Series Connection see 6SBEU24DI.370 Compatible Connection Cable GST15i5 for 5-pole input connector see 6SACP5J516B.2000 Compatible Connection Cable GST18i3 for 3-pole output connector see 6SACP3J316B.2000 Compatible Connection Coupling GST18i3 for 3-pole output connector see 6SAKP3J316BS01 Compatible Cover Cap GST18i3 for 3-pole output connector see 063SGF3S01 Compatible Direct Connector I, slot 8 see 099DC084040N08 Compatible Direct Connector I / B, Slot 8 / 10 see 099DC084045N10Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 wattsSpecials:Other lengths, other colors on requestDelivery Countries:Worldwide

Description:For the simple creation of high-quality storage areas at work stationsMaterial:AluminumSurface:AnodizedTip:Compatible Cover Caps see 061CC42300.74 # Compatible Direct Connector I, Slot 8 see 099DC084040N08 Compatible Direct Connector I / B, Slot 8 / 10 see 099DC084045N10 Compatible T-Connector Plate see 093VAD28VTip 2:For cut: To order, please replace "1188" in the part number by the required length in mm, e.g. "0350" for 350 mm or "2000" for 2000 mmDelivery Countries:Worldwide
