FIFO Monorail Rails
Connecting Element for FIFO Monorail Rail 40 and 55 (Set)
€0.00*
Delivery Countries:WorldwideDescription:For parallel connection of two FIFO Monorail rails, as spacer for aligning the track; To be screwed on infeed caps with enclosed screwsMaterial:Stainless steelSurface:PlainTip:Compatible FIFO Monorail Rail 40 see 02082PO.1200 Compatible FIFO Monorail Rail 55 see 02082PO55.1200 Compatible Infeed cap for FIFO Monorail Rail 40 (Set) see 02082CCS02 Compatible Infeed cap for FIFO Monorail Rail 55 (Set) see 02082CC55Zolltarifnummer:73269098900
Connecting Strip 180 B, Slot 8
€0.00*
A1 (mm):
80.0
|
A2 (mm):
160.0
|
Fig.:
①
|
L (mm):
180.0
|
M:
M6
|
Profile:
B
|
Slot N (mm):
8
|
Version:
-
Assembly Set:4 screws DIN EN ISO 4762 (DIN 912) - M6 x 12, 4 washers DIN 7349 - 6.4Delivery Countries:WorldwideDescription:End-to-end connection of two aluminum profiles without machiningMaterial:SteelSurface:Zinc platedZolltarifnummer:73181900900
Cover Profile Slot 8 - 2.2
€0.00*
Color:
Yellow ≈ RAL 1018
|
ESD:
-
|
Profile:
B
|
Slot N (mm):
8
Color:Black, yellow, red, blue, gray, white, natural, aluminum colorDelivery Countries:WorldwideDescription:To cover T-Slots with 8 width and a 2.2 mm profile webMaterial:Plastic PPSpecials:Other colors on requestTip:ESD electrostatical discharging version: Notch at the bottom sideZolltarifnummer:39169050900
FIFO Monorail Rail 40
€0.00*
L (mm):
2400.0
|
Profile:
B
Delivery Countries:WorldwideDescription:For guiding floor dollys on one side in FIFO stations, with a wheel width of up to 40 mm 2 slots at the top, set at 45°; closed back side for optional full-surface adhesion to the floor To extend two guiding rails, connect them face to face with connecting strip in the slots; posts can be mounted in the slot from aboveMaterial:AluminumSurface:AnodizedTip:Compatible Connecting Strip see 096010S11 Compatible Infeed Cap for FIFO Monorail Rail (set) see 2082CCS02 Compatible Monorail Angle Connector for Post see 093WS30145S01 Compatible Mounting Set for Posts Support Struts see 93WS30145S02 Compatible Cover Profiles see 092050Zolltarifnummer:76042990900
FIFO Monorail Rail 55
€0.00*
L (mm):
2400.0
|
Profile:
B
Delivery Countries:WorldwideDescription:For guiding floor dollys on one side in FIFO stations, with a wheel width of up to 55 mm 2 slots at the top, set at 45°; closed back side for optional full-surface adhesion to the floor To extend two guiding rails, connect them face to face with connecting strip in the slots; posts can be mounted in the slot from aboveMaterial:AluminumSurface:AnodizedTip:Compatible Connecting Strip see 096060S20 Compatible Infeed Cap for FIFO Monorail Rail (set) see 02082CC55 Compatible Monorail Angle Connector for Post see 093WS30145S01 Compatible Mounting Set for Posts Support Struts see 93WS30145S02 Compatible Cover Profiles see 092080Zolltarifnummer:76042990900
FIFO Monorail Station 40 (Set)
€0.00*
L (mm):
2400.0
|
Profile:
B
Color:Infeed caps: BlackDelivery Countries:WorldwideDescription:Fast mounting FIFO station for guiding floor dollys on one side in FIFO stations, with a wheel width of up to 40 mm; To extend guiding rails, connect them face to face with connecting strip in the slots; To widen, connect further parallel guided guiding rails and end caps with connecting elements Posts can be mounted in the slot from aboveMaterial:Rails: Aluminum Infeed caps: Aluminum die-cast Hexagon socket set screws: Steel Connecting elements: Stainless steel Screws: SteelSet:5 FIFO Monorail Rails 40, 10 infeed caps, 20 hexagon socket set screws ISO 4027 - M6 x 8, 8 connecting elements, 32 screws DIN 7991 (ISO 10642) - M6 x 16Surface:Rails: Anodized Infeed caps: Powder coated Hexagon socket set screws: Zinc plated Screws: Zinc platedZolltarifnummer:76169990990
Infeed cap for FIFO Monorail Rail 40 (Set)
€0.00*
Color:Infeed caps: BlackDelivery Countries:WorldwideDescription:For easier loading and unloading of FIFO stations with floor dollies; Robust design, mounting directly in the slot of FIFO monorail rail with enclosed hexagon socket set screwsMaterial:Infeed caps: Aluminum die-cast Hexagon socket set screws: SteelSet:8 infeed caps 16 hexagon socket set screws ISO 4027 - M6 x 8Surface:Infeed caps: Powder coated Hexagon socket set screws: Zinc platedTip:Compatible FIFO Monorail Rail 40 see 02082PO.1200Zolltarifnummer:39269097900
Infeed cap for FIFO Monorail Rail 55 (Set)
€0.00*
Color:Infeed caps: BlackDelivery Countries:WorldwideDescription:For easier loading and unloading of FIFO stations with floor dollies; Robust design, mounting directly in the slot of FIFO monorail rail with enclosed hexagon socket set screwsMaterial:Infeed caps: Aluminum die-cast Hexagon socket set screws: SteelSet:8 infeed caps 16 hexagon socket set screws ISO 4027 - M6 x 8Surface:Infeed caps: Powder coated Hexagon socket set screws: Zinc platedTip:Compatible FIFO monorail rail 55 see 02082PO55.1200Zolltarifnummer:76169990990
