Guiding Rails FIFO
Adjustable Caster End Stop for Guiding Rail FIFO (Set)
€0.00*
L (mm):
178.0
|
Profile:
I
Color:Cover caps: Gray ≈ RAL 7042Delivery Countries:WorldwideDescription:To stop dollies in guiding rails FIFO; Easy installation with enclosed connectorsMaterial:Profile: Aluminum Cover Cap: Plastic PA Connector: SteelSet:1 profile piece 2 cover caps 2 connectorsSurface:Profile: Anodized Connector: Zinc platedTip:Compatible Guiding Rail FIFO see 02082P.1200Zolltarifnummer:76169990990
Brush Brake for Guiding Rail FIFO
€0.00*
Color:Bristles: BlackDelivery Countries:WorldwideDescription:For braking and stopping dollies in guiding rails; Variable fixable via slot of the guide rail FIFOMaterial:Body : Aluminum Bristles: Plastics PASurface:Body : AnodizedTip:Compatible Guiding Rail FIFO see 02082P.1200Zolltarifnummer:96035000000
Connecting Element for Guiding Rail FIFO (Set)
€0.00*
Delivery Countries:WorldwideDescription:For parallel connection of two guiding rails FIFO, as spacer for aligning the track; To be screwed on infeed caps with enclosed screwsMaterial:Stainless steelSet:2 connecting elements 8 screws DIN 7991 (ISO 10642) - M6 x 16Surface:PlainTip:Compatible Guiding Rail FIFO see 02082P.1200 Compatible Infeed Cap for Guiding Rail FIFO (set) see 02082CCS01Zolltarifnummer:73269098900
Connecting Strip 140 I, Slot 8 (Set)
€0.00*
L (mm):
140.0
|
M:
M8
|
Profile:
I
|
Slot N (mm):
8
Delivery Countries:WorldwideDescription:End-to-end connection of two aluminum profiles without machiningMaterial:SteelSet:1 connecting strip 140 - slot 8 4 screws DIN 914 - M8 x 10Surface:Zinc platedZolltarifnummer:73181900900
Cover Profile Slot 8 - 4.5
€0.00*
Color:
Black
|
ESD:
ESD electrostatical discharging
|
Profile:
I
|
Slot N (mm):
8
Color:Black, yellow, gray, natural, alu colorDelivery Countries:WorldwideDescription:To cover T-Slots with 8 mm width and a 4.5 mm profile webMaterial:Plastic PPSpecials:Other colors on requestZolltarifnummer:39169050900
Floor Mounting for Guiding Rail FIFO (Set)
€0.00*
Color:Angle: Alu color Anchors: YellowDelivery Countries:WorldwideDescription:To additionally mount guiding rails FIFO to the floorMaterial:Angle: Steel Screw: Steel T-slot nut: Steel Anchors: PlasticSet:2 steel connection angle 20, 2 screws DIN 7991 - M5 x 8; 2 T-slot nuts - slot 5 - M5, 2 screws 5 x 60, 2 anchors 8 x 60Surface:Angle: Powder coated Screws: Zinc plated T-slot nuts: Zinc platedZolltarifnummer:73269098900
Guiding Rail FIFO (Set)
€0.00*
L (mm):
2400.0
|
Profile:
I
Delivery Countries:WorldwideDescription:For guiding floor dollys on one side in FIFO stations, with a wheel width of up to 40 mm with 2 slots at the top, bottom and sides; to extend two guiding rails, connect them face to face with connecting strip in the slots; sign posts can be mounted in the slot from aboveMaterial:AluminumSurface:AnodizedTip:For cut: To order, please replace "xxxx" in the part number by the required length in mm, e.g. "0350" for 350 mm or "2000" for 2000 mm Compatible connecting strip see 096060S20 Compatible infeed cap for FIFO monorail rail (set) see 2082CCS02 Compatible monorail angle connector for post see 093WS30145S01 Compatible mounting set for posts support struts see 93WS30145S02 Compatible cover profiles see 092080Zolltarifnummer:76042990900
Infeed Cap for Guiding Rail FIFO (Set)
€0.00*
Color:Screw Covers: Yellow ≈ RAL 1003Delivery Countries:WorldwideDescription:For easier loading and unloading of a FIFO stations with floor dollys; Robust design, mounting directly in the slot of guiding rails FIFO with enclosed hexagon socket set screws Yellow screw cover with signal effect to indicate the infeed position for the wheels of floor dollysMaterial:Infeed caps: Aluminum die-cast Screw covers: Plastic PC Hexagon socket set screws: SteelSet:8 infeed caps 16 screw covers 16 hexagon socket set screws ISO 4027 - M6 x 8Surface:Infeed caps: Alu color powder coated Hexagon socket set screws: Zinc platedTip:Compatible Guiding Rails FIFO see 02082P.1200 Compatible Connecting Element for Guiding Rail FIFO see 02082D Compatible Fastening Set see 02082FS Compatible Screw Cover Infeed Cap for Guiding Rail FIFO as spare part see 02082S.15Zolltarifnummer:76169990990
Mounting Set Infeed Cap for Guiding Rail FIFO
€0.00*
Color:Anchor: YellowDelivery Countries:WorldwideDescription:To mount infeed caps for guiding rails FIFO to the floorMaterial:Anchor: Plastic Screws: SteelSet:8 anchors 8 x 60 8 screws 5 x 60Surface:Screws: GalvanizedZolltarifnummer:73269098900
Screw Cover Infeed Cap for Guiding Rail FIFO
€0.00*
Color:Yellow ≈ RAL 1003Delivery Countries:WorldwideDescription:To cover the screw holes of infeed caps for guiding rail FIFO; Yellow screw cover with signal effect to indicate the infeed position for the wheels of floor dollys; Included in the infeed cap set, here separately available as replacementMaterial:Plastic PCZolltarifnummer:39269097900
