Swivel Caster Ø 80 / 100 / 125

Product information "Swivel Caster Ø 80 / 100 / 125"

Color:
Housing: Alu color
Tread: See table
Wheel body: Black, gray

Delivery Countries:
Worldwide

Description:
Reliable and quiet swivel caster, trackless (except solid rubber ESD electrostatical discharging), with ball bearings and thread guard; can be fixed to aluminum profiles; compatible with all swivel and fixed casters due to consistent height level with optional adapter plate S; no additional transport and base plate needed

Material:
Housing: Steel
Tread: See table
Wheel body: See table

Specials:
Other kinds of wheels, other colors, other surfaces on request

Surface:
Housing: Powder coated

Tip:
Compatible Adapter Plate for Swivel Casters Ø 80 / 100 / 125 see 098SA40N08

Pack Quantity:	1 piece
Model:	With bolt hole; compatible with optional adapter plate S
Weight (g):	660.0
ERP Number:	139767

Variants

Part #	D (mm)	H (mm)	ESD	Max. Load (N)	Swivel Caster Tread	Wheel Body
098S080TN	80	108	-	1000	TPE, gray ≈ RAL 7031	PP, gray
098S100TN	100	133	-	1100	TPE, gray ≈ RAL 7031	PP, gray
098S125TN	125	158	-	1200	TPE, gray ≈ RAL 7031	PP, gray
098S080TNESD	80	108	ESD	650	TPE, gray ≈ RAL 7031	PP, black
098S100TNESD	100	133	ESD	700	TPE, gray ≈ RAL 7031	PP, black
098S125TNESD	125	158	ESD	800	TPE, gray ≈ RAL 7031	PP, black
098S080UN	80	108	-	1200	TPU, gray ≈ RAL 7024	PP, black
098S100UN	100	133	-	1200	TPU, gray ≈ RAL 7024	PA, gray
098S125UN	125	158.0	-	1200	TPU, gray ≈ RAL 7024	PA, gray
098S080UNESD	80	108	ESD	1000	TPU, gray ≈ RAL 7024	PA, black
098S100UNESD	100	133	ESD	1200	TPU, gray ≈ RAL 7024	PA, black
098S125UNESD	125	158	ESD	1200	TPU, gray ≈ RAL 7024	PA, black
098S080GN	80	108	-	800	Solid rubber, gray ≈ RAL 7001	PA, black
098S100GN	100	133	-	1100	Solid rubber, gray ≈ RAL 7001	PA, black
098S125GN	125	158	-	1000	Solid rubber, gray ≈ RAL 7001	PA, black
098S080GNESD	80	108	ESD	600	Solid rubber, black	PA, black
098S100GNESD	100	133	ESD	800	Solid rubber, black	PA, black
098S125GNESD	125	158	ESD	750	Solid rubber, black	PA, black
098S080AN	80	108	-	1000	PA, black; *with slide bearings	PA, black
098S100AN	100	133	-	1200	PA, black; *with slide bearings	PA, black
098S125AN	125	158	-	1200	PA, black; *with slide bearings	PA, black
