SOLUTIONS FOR INDUSTRIAL ECOSYSTEMS


ENGINEERING
COMPONENTS


With the wide range of FATH mechanical engineering components, you can build almost any structure based on aluminum profiles. Even combining different profile systems is no problem with our versatile portfolio.

ALL PRODUCTS IN CAD FORMAT

Learn more

FATH Products CAD Download

PARTcommunity CADENASIcon-link-extern.svg?ts=1745831337

FATH Products CAD Download

TracePartsIcon-link-extern.svg?ts=1745831337

FATH component library

Plugin 3DfinditIcon-link-extern.svg?ts=1745831337

NEW PRODUCTS

ALL PRODUCTS

Skip product gallery
Bag Cutter FX for Square Holes 9 x 9 (8.7 x 8.7)
Bag Cutter FX for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black | ESD: ESD electrostatical discharging
Color:Holder: Black Bag cutter: BlackDelivery Countries:WorldwideDescription:Ready to use bag cutter, changeable blade, 360° turnable, for perforated metals up to 1.4 mm thick; To organize workstations, with labeling area for standard labelsMaterial:Holder ESD electrostatical discharging version: Plastic PA, carbon fibre reinforced Bag cutter ESD electrostatical discharging version: Plastic PA, glass ball reinforced with carbon Trapezoidal blade: Carbon steel Spring: Spring steel SS313 Countersunk screw: Brass Sleeve nut: Brass Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TM840NF91S01 For round tubes D28 / D30 see 6TM8D283F91ESDS01

€0.00*
LED Lamp Module F Line 953 Dimmable, for Series Connection
LED Lamp Module F Line 953 Dimmable, for Series Connection
Profile: I | Slot N (mm): 8
Color:Housing: - End caps: Black Diffusing screen: TransparentDelivery Countries:WorldwideDescription:Remotely dimmable LED Lamp for power and light supply at work stations On the backside with slot 8 for mounting on aluminum profiles Can be dimmed in series if the upstream Power Strip or LED Lamp for Series Connection has a dimmer switchMaterial:Housing: Aluminum End caps: Plastic PA, carbon fibre reinforced Diffusing screen: PolycarbonateSpecials:Other lengths, other colors on requestSurface:Housing standard version: AnodizedTip:Compatible LED Lamp Module F Line 953 Dimmable, with Button, for Series Connection see 6SL1040RDI.953 Compatible Power Strip Module F Line 370 4xEU with Switch and Dimmer Button, for Series Connection see 6SBEU24DI.370 Compatible Connection Cable GST15i5 for 5-pole output connector see 6SACP5J516B.2000 Compatible Connection Coupling GST15i5 for 5-pole output connector see 6SAKP5J516BS01 Compatible Direct Connector I, slot 8 see 099DC084040N08 Compatible Direct Connector I / B, Slot 8 / 10 see 099DC084045N10Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 watts

€0.00*
Ball Insert D24
Ball Insert D24
ESD: ESD | Fig.: ② | Max. Load (N): - | Version: Steel ball, with Housing Attachment Clip
Delivery Countries:WorldwideDescription:Low-wear, low friction ball caster for flexible movements in two directions, for example at track switches and material locks; for roller tracks AL, can also be used in panels, e.g. on table tops; version with attachement clip prevents rotation of the ball housingMaterial:Ball: Steel, stainless steel Ball housing: Steel Housing Attachment Clip: SteelSpecials:Other materials, other surfaces on requestSurface:Ball steel: Chrome plated / Ball stainless steel: Plain Ball housing: Chrome plated Housing Attachment Clip: Zinc platedTip:Compatible Cage for Ball / Bush Insert D24 see 062ACD2491ESD.50;

€0.00*
Angle Element T1 80 x 40, 45°
Angle Element T1 80 x 40, 45°
Profile: I | Slot N (mm): 8
Color:Alu colorDelivery Countries:WorldwideDescription:To mount a profile as bracing at a 45° angle without miter cutMaterial:AluminumSurface:AnodizedTip:Compatible Cover Cap 40 x 40 45° see 091048 (black) / 091048S01 (gray)

€0.00*
Double Bearing Unit 2 Rollers Eccentric Shaft Ø 14
Double Bearing Unit 2 Rollers Eccentric Shaft Ø 14
Profile: I
Delivery Countries:WorldwideDescription:To build sliding carriages To linearly guide loads, steel roller with ball bearings runs directly on shaft Ø 14 mm Completely pre-assembled from roller profile I slot 8 To tighten the eccentric screw, a pin spanner is needed for the four holes of the adjusting washerMaterial:Roller: Steel Screws: Steel Excentric screw: Steel Adjusting washer: Steel Washers: Steel Tension pins: Steel Profile: AluminumSurface:Roller: Zinc plated Screws: Zinc plated Excentric screw: Zinc plated Adjusting washer: Zinc plated Washers: Zinc plated Tension pins: Zinc plated Profile: AnodizedTip:Compatible Wiper and Lubricator Ø 14 for Roller Profile I Slot 8 (Set) see 091381S01

€0.00*
Broom Holder FLEX FX 20 - 30 for Square Holes 9 x 9 (8.7 x 8.7)
Broom Holder FLEX FX 20 - 30 for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black
Color:Holder: Black Broom holder: Black Retaining strap: BlackDelivery Countries:WorldwideDescription:Ready to use broom holder to hang up tools with Ø 20 up to 30 mm diameter, 360° turnable, for perforated metals up to 1.4 mm thick; To organize workstations, with labeling area for standard labelsMaterial:Holder: Plastic PA, carbon fibre reinforced Broom holder: Plastic PA, glass ball reinforced Retaining strap FLEX: Plastic TPE Bushings: Steel Screws for retaining strap: Steel Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TM840NX2030S01 For round tubes D28 / D30 see 6TM8D283X2030S01

€0.00*
Gusseted Connection Angle AL 4 Hole, 1 Slot Version
Gusseted Connection Angle AL 4 Hole, 1 Slot Version
A (mm): 90.0 | B (mm): 90.0 | C (mm): 6.0 | Color: Black | D (mm): 20.5 | E (mm): 20.0 | F (mm): 41.0 | G (mm): 22.5 | Grid: 45 | H (mm): 45.0 | J (mm): 9.0
Color:Alu color, blackDelivery Countries:North AmericaDescription:To connect two aluminum profiles at right anglesMaterial:AluminumSurface:Anodized

€0.00*
Power Strip Module F Line 317 4x, with Dimmer Button, for Series Connection
Power Strip Module F Line 317 4x, with Dimmer Button, for Series Connection
ESD: - | Fig.: ② | Profile: I | Slot N (mm): 8 | Socket Type: Type G: BS 1363
Color:Housing standard version: - Housing ESD electrostatical discharging version: Black End caps: Black Socket inserts: Black Dimmer button standard version: Blue Dimmer button ESD electrostatical discharging version: OrangeDelivery Countries:WorldwideDescription:Power strip with sockets for power supply at workstations; With remote dimming for series-connected LED lamps Modul F Line; Combination on output side only possible with remote dimmable LED lamp Modul F Line; On the backside with slot 8 for mounting on aluminum profilesMaterial:Housing: Aluminum End caps: Plastic PA, carbon fibre reinforced Socket inserts: Plastic PA Button: Plastic ABS / PASpecials:Further colors, individually configurated power strips on requestSurface:Housing standard version: Anodized Housing ESD electrostatical discharging version: Powder coatedTip:Compatible LED lamp see 6SL0040I.953 Compatible main power cable see 6SAME4J316B.2000 Compatible connection cable see 6SACP3J316B.2000 Compatible connection cable see 6SACP5J516B.2000 Compatible Connection Coupling see 6SAKP3J316BS01 Compatible direct connector I, slot 8 see 099DC084040N08 Compatible direct connector I / B, Slot 8 / 10 see 099DC084045N10Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 watts

€0.00*
Tool Hook FX 66/27 - 13, Rubberized for Square Holes 9 x 9 (8.7 x 8.7)
Tool Hook FX 66/27 - 13, Rubberized for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black
Color:Wire: Black coated Rear mounting holder: Black Front locking holder: BlackDelivery Countries:WorldwideDescription:Ready to use tool hook, 360° turnable, for perforated metals up to 1.4 mm thick; Rubber coated wire to prevent tools from slipping; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder: Plastic PA, carbon fibre reinforced Front locking holder: Plastic PA, glass ball reinforced Wire: Stainless steel SS304 Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Wire: PVC coated Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TH240NA903091S01 For round tubes D28 / D30 see 6TH2D283A903091S01

€0.00*
RIBE® Aluform Bolt
RIBE® Aluform Bolt
Size M x L (mm): M4 x 16 | TX: T20 | h (mm): 3.1 | ØD (mm): 8.0
Delivery Countries:WorldwideDescription:For the material-matched connection of aluminum componentsand for electrical contact screw connections; Corrosion-resistant, easy to recycle, approx. 2/3 weight saving compared to similar steel screws; Reduced electrical contact resistanceMaterial:AluminumSurface:With dry film lubrication

€0.00*
LED Lamp Module F Line 476 Dimmable
LED Lamp Module F Line 476 Dimmable
ESD: ESD | Profile: I | Slot N (mm): 8
Color:Housing standard version: - Housing ESD electrostatical discharging version: Black End caps: Black Diffusing screen: Transparent Dimmer button standard version: Blue Dimmer button ESD electrostatical discharging version: OrangeDelivery Countries:WorldwideDescription:Remote dimmable LED Lamp for power and light supply at work stations Input side only compatible with power strip Modul F Line with dimmable exit On the backside with slot 8 for mounting on aluminum profilesMaterial:Housing: Aluminum End caps: Plastic PA, carbon fibre reinforced Diffusing screen: Polycarbonate Dimmer button: Plastic ABS/PASpecials:Other lengths, other colors on requestSurface:Housing standard version: Anodized Housing ESD electrostatical discharging version: Powder coatedTip:Compatible Power Strip Module F Line 370 4x, with Switch and Dimmer Button, for Series Connection see 6SBEU24DI.370 Compatible Connection Cable GST15i5 for 5-pole input connector see 6SACP5J516B.2000 Compatible Connection Cable GST18i3 for 3-pole output connector see 6SACP3J316B.2000 Compatible Connection Coupling GST18i3 for 3-pole output connector see 6SAKP3J316BS01 Compatible Cover Cap GST18i3 for 3-pole output connector see 063SGF3S01 Compatible Direct Connector I, slot 8 see 099DC084040N08 Compatible Direct Connector I / B, Slot 8 / 10 see 099DC084045N10Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 watts

€0.00*
Double T-slot Nut I Slot 8 for Double Adapter D30 (Set)
Double T-slot Nut I Slot 8 for Double Adapter D30 (Set)
M: M6 | Profile: I
Delivery Countries:WorldwideDescription:Roll-in double T-slot nutMaterial:Double T-slot nut: Steel Ball: Stainless steel Spring: Spring steel Screws: SteelSet:1 roll-in double T-slot nut I slot 8 2 screws DIN EN ISO 4762 (DIN 912) - M6 x 16Surface:Double T-slot nut: Zinc-plated Ball: Plain Spring: Plain Screws: Zinc-plated

€0.00*
Tool Hook FX 59/19 - 24 for Square Holes 9 x 9 (8.7 x 8.7)
Tool Hook FX 59/19 - 24 for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black | ESD: ESD electrostatical discharging
Color:Rear mounting holder: Black Front locking holder: BlackDelivery Countries:WorldwideDescription:Ready to use tool hook, 360° turnable, for perforated metals up to 1.4 mm thick; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder ESD electrostatical discharging version: Plastic PA, carbon fibre reinforced Front locking holder ESD electrostatical discharging: Plastic PA, glass ball reinforced with carbon Wire: Stainless steel SS304 Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TH240NA8020S01 For round tubes D28 / D30 see 6TH2D283A8020EDS1-

€0.00*
Angle Element T2 40, 45°
Angle Element T2 40, 45°
Profile: I | Slot N (mm): 8
Color:Alu colorDelivery Countries:WorldwideDescription:To mount two profiles as bracing at a 45° angle without miter cutMaterial:AluminumSurface:AnodizedTip:Compatible Cover Cap 40 x 40 45° see 091048 (black) / 091048S01 (gray)

€0.00*
Power Strip Module F Line 370 5x with Switch
Power Strip Module F Line 370 5x with Switch
Profile: I | Slot N (mm): 8 | Socket Type: Type F: CEE 7/3
Color:Housing: - End caps: Black Socket inserts: Black Switch: BlueDelivery Countries:WorldwideDescription:Switchable power strip with sockets for power supply at workstations; On the backside with slot 8 for mounting on aluminum profilesMaterial:Housing: Aluminum End caps: Plastic PA, carbon fibre reinforced Socket inserts: Plastic PA Switches: Plastic ABS / PASpecials:Further colors, individually configurated power strips on requestSurface:Housing: AnodizedTip:Compatible LED Lamp see 6SL1040DI.953 Compatible Main Power Cable see 6SAME4J316B.2000 Compatible Connection Cable see 6SACP3J316B.2000 Compatible Connection Coupling see 6SAKP3J316BS01 Compatible Cover Cap for 3 pole female connector see 063SGF3S01 Compatible Direct Connector I, Slot 8 see 099DC084040N08 Compatible Direct Connector I / B, Slot 8 / 10 see 099DC084045N10Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 watts

€0.00*
Connection Coupling GST15i5 for Module F Line (Set)
Connection Coupling GST15i5 for Module F Line (Set)
Color:Connection coupling: BlackDelivery Countries:WorldwideDescription:5 pole coupling piece to directly connect LED lamps and power strips Module F LineMaterial:Connection coupling: Plastic PA Connector T-slot nut: SteelSet:1 connection coupling 1 connector T-slot nut 4 grub screws M8 x 10 mmSurface:Connector T-slot nut: Zinc-platedTip:Compatible Power Strip see 6SBEU24DI.370 Compatible LED Lamp see 6SL0040RI.476Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 watts

€0.00*
Tool Double Hook FX R35 - 67, Rubberized for Square Holes 9 x 9 (8.7 x 8.7)
Tool Double Hook FX R35 - 67, Rubberized for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black
Color:Wire: Black coated Rear mounting holder: Black Front locking holder: BlackDelivery Countries:WorldwideDescription:Ready to use double tool hook, 360° turnable, for perforated metals up to 1.4 mm thick; Rubber coated wire to prevent tools from slipping; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder: Plastic PA, carbon fibre reinforced Front locking holder: Plastic PA, glass ball reinforced Wire: Stainless steel SS304 Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Wire: PVC coated Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TH240NR3091S01 For round tubes D28 / D30 see 6TH2D283R3091S01

€0.00*
Direct Connector I 90°, Slot 8
Direct Connector I 90°, Slot 8
Profile: I | Slot N (mm): 8
Delivery Countries:WorldwideDescription:To connect two aluminum profiles at right angles, before the application one core hole must be M8 threaded (min. 18 mm deep)Material:Stainless steel

€0.00*
Angle Element T2 80 x 40, 45°
Angle Element T2 80 x 40, 45°
Profile: I | Slot N (mm): 8
Color:Alu colorDelivery Countries:WorldwideDescription:To mount two profiles as bracing at a 45° angle without miter cutMaterial:AluminumSurface:AnodizedTip:Compatible Cover Cap 40 x 40 45° see 091048 (black) / 091048S01 (gray)

€0.00*
Tool Tray PARABOL FX for Square Holes 9 x 9 (8.7 x 8.7)
Tool Tray PARABOL FX for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black | ESD: ESD electrostatical discharging
Color:Rear mounting holder: Black Front locking adapter: Black Tool tray: Black Tool insert: BlackDelivery Countries:WorldwideDescription:Ready to use tool tray, 360° turnable, tilt-adjustable in 5 ways, for perforated metals up to 1.4 mm thick; Suitable for heavy tools or nutrunners; tool friendly surface; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder ESD electrostatical discharging version: Plastic PA, carbon fibre reinforced Front locking adapter ESD electrostatical discharging: Plastic PA, glass ball reinforced with carbon Tool tray ESD electrostatical discharging version: Plastic PA, glass ball reinforced with carbon Tool insert ESD electrostatical discharging version: Plastic TPE, ≈ 80 Shore A, with carbon Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TM840NV12591S01 For round tubes D28 / D30 see 6TM8D283V12591ESDS01

€0.00*

CATALOG ENGINEERING COMPONENTS

Flip PDF PDF Download

EN | icon-download-white.svg?ts=1738761470 113 MB | February 2024

GEOMETRY OF ALUMINUM PROFILES

To make orientation easier for you, we have specified the geometry of the respective compatible aluminum profile where appropriate.In addition, you will find detailed dimensions and tolerances of the most important profile shapes in the table.

As before: FATH will not be offering a profile system of its own.

DOWNLOAD PDF

INDIVIDUAL CONSULTATION

For further information and advice on the compatibility of your aluminum profile, please contact our sales team.

CONTACT
