With the wide range of FATH mechanical engineering components, you can build almost any structure based on aluminum profiles. Even combining different profile systems is no problem with our versatile portfolio.

ALL PRODUCTS IN CAD FORMAT

FATH Products CAD Download

PARTcommunity CADENASIcon-link-extern.svg?ts=1745831337

FATH Products CAD Download

TracePartsIcon-link-extern.svg?ts=1745831337

FATH component library

Plugin 3DfinditIcon-link-extern.svg?ts=1745831337

NEW PRODUCTS

Skip product gallery
Roll-in T-slot Nut 13.4 x 7.6 mm with Large Spring Loaded Ball
M: M4
Delivery Countries:WorldwideDescription:Self-aligning roll-in T-slot nut with spring loaded ballMaterial:SteelSpecials:ESD electrostatical discharging, different lengths with multiple threads in different sizes available on requestSurface:Zinc plated

€0.00*
Tool Hook FX R35 - 27, Rubberized for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black
Color:Wire: Black coated Rear mounting holder: Black Front locking holder: BlackDelivery Countries:WorldwideDescription:Ready to use tool hook, 360° turnable, for perforated metals up to 1.4 mm thick; Rubber coated wire to prevent tools from slipping; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder: Plastic PA, carbon fibre reinforced Front locking holder: Plastic PA, glass ball reinforced Wire: Stainless steel SS304 Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Wire: PVC coated Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TH240NR4091S01 For round tubes D28 / D30 see 6TH2D283R4091S01

€0.00*
LED Lamp Module F Line 476 Dimmable, for Series Connection
Profile: I | Slot N (mm): 8
Color:Housing: - End caps: Black Diffusing screen: TransparentDelivery Countries:WorldwideDescription:Remotely dimmable LED Lamp for power and light supply at work stations On the backside with slot 8 for mounting on aluminum profiles Can be dimmed in series if the upstream Power Strip or LED Lamp for Series Connection has a dimmer switchMaterial:Housing: Aluminum End caps: Plastic PA, carbon fibre reinforced Diffusing screen: PolycarbonateSpecials:Other lengths, other colors on requestSurface:Housing standard version: AnodizedTip:Compatible LED Lamp Module F Line 476 Dimmable, with Button, for Series Connection see 6SL1040RDI.476 Compatible Power Strip Module F Line 370 4xEU with Switch and Dimmer Button, for Series Connection see 6SBEU24DI.370 Compatible Connection Cable GST15i5 for 5-pole output connector see 6SACP5J516B.2000 Compatible Connection Coupling GST15i5 for 5-pole output connector see 6SAKP5J516BS01 Compatible Direct Connector I, slot 8 see 099DC084040N08 Compatible Direct Connector I / B, Slot 8 / 10 see 099DC084045N10Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 watts

€0.00*
Cover Profile Slot 8 - 2.2
Color: Yellow ≈ RAL 1018 | ESD: - | Profile: B | Slot N (mm): 8
Color:Black, yellow, red, blue, gray, white, natural, aluminum colorDelivery Countries:WorldwideDescription:To cover T-Slots with 8 width and a 2.2 mm profile webMaterial:Plastic PPSpecials:Other colors on requestTip:ESD electrostatical discharging version: Notch at the bottom side

€0.00*
Bottle Holder FX for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black
Color:Rear mounting holder: Black Front locking holder: BlackDelivery Countries:WorldwideDescription:Ready to use bottle holder, 360° turnable, for perforated metals up to 1.4 mm thick; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder: Plastic PA, carbon fibre reinforced Front locking holder: Plastic PA, glass ball reinforced Wire: Stainless steel SS304 Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TM840ND100S01 For round tubes D28 / D30 see 6TM8D283D100S01

€0.00*
Monitor Support 4-axis, Height Adjustable (Set)
Fmax (N): - | Version: 8 - 20 kg
Color:Mounting plate VESA, removable: Alu color / black Monitor mount: Alu color Cable management cover: Black Bearing shims and bushes: Black Mounting flange: Alu color Mounting adapter: alu colorDelivery Countries:WorldwideDescription:For removable mounting of monitors with 2 - 10 kg or 8 - 20 kg, mounting plate VESA MIS-D 75/100 compatible; Adjustable viewing angle and height, screen rotatable by 90°; 360° mounting flange for horizontal and vertical attachment with mounting adapterMaterial:Mounting plate VESA, removable: Steel / Plastic Monitor mount: Die-cast aluminum Cable management cover: Plastic Bearing shims and bushes: Plastic Mounting flange: Die-cast aluminum Mounting adapter: Die-cast aluminum Screws: SteelSet:1 mounting plate VESA with 4 screws – M4 × 12, Phillips 1 monitor support 4-axis with cable management cover 1 mounting flange 1 mounting screw DIN 6912 – M8 × 25 1 mounting adapter 2 mounting screws DIN 6912 – M8 × 16 1 hexagon key, AF 3 1 hexagon key, AF 4Surface:Mounting plate VESA, removable: Lacquered Monitor mount: Lacquered Mounting flange: Lacquered Mounting adapter: Lacquered Screws: Zinc plated

€0.00*
RCD Unit 25A / 30mA, Module F Line 185
Profile: I | Slot N (mm): 8
Color:End caps: Black RCD-Unit: WhiteDelivery Countries:WorldwideDescription:Residual current circuit breaker (RCCB) for protecting downstream F-Line modules in a chain against fault currents On the backside with slot 8 for mounting on aluminum profilesMaterial:Housing: Aluminum End caps: Plastic PA, carbon fibre reinforced RCD Unit: Plastic ABSSpecials:ESD electrostatical discharging, available on requestSurface:Housing: AnodizedTip:Compatible Main Power Cable GST18i3 for 3-pole input connector see 6SAME4J316B.2000 Compatible Connection Cable GST18i3 for 3-pole output connector see 6SACP3J316B.2000 Compatible Power Strip Module F Line 264 4x see 6SBEU04I.264Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 watts

€0.00*
Slot-on-Slot Connector SOS I8 360°
A2 (Profile) (mm): 4.4 (4.5) | Color: Gray ≈ RAL 7042 | Version: I8 / I8
Color:GrayDelivery Countries:WorldwideDescription:To cross or parallel connect two aluminum profiles at various angles; fast, tool-free assembly without machiningMaterial:Plastic PA, glass fiber reinforcedSpecials:Customized hammer, other colors on requestTip:Compatible Power Strip see 6SBEU04I.264 Compatible LED Lamp see 6SL0040I.953 Compatible Shelf Board AL see 061AS300N08.788Tip 2:For one connection at least two Slot-on-Slot connectors SOS 360° are required

€0.00*
LED Lamp Module F Line 953 Dimmable, with Button, for Series Connection
Profile: I | Slot N (mm): 8
Color:Housing standard version: - End caps: Black Diffusing screen: Transparent Dimmer button standard version: BlueDelivery Countries:WorldwideDescription:LED Lamp with dimmer button for power and light supply at work stations On the backside with slot 8 for mounting on aluminum profiles Can be dimmed in series if the downstream LED Lamp for Series Connection is dimmableMaterial:Housing: Aluminum End caps: Plastic PA, carbon fibre reinforced Diffusing screen: Polycarbonate Dimmer button: Plastic ABS/PASpecials:Other lengths, other colors on requestSurface:Housing standard version: AnodizedTip:Compatible LED Lamp Module F Line 953 Dimmable, for Series Connection see 6SL0040RI.953 Compatible Power Strip Module F Line 264 4xEU see 6SBEU04I.264 Compatible Main Power Cable GST18i3 for 3-pole input connector see 6SAME4J316B.2000 Compatible Connection Cable GST18i3 for 3-pole output connector see 6SACP3J316B.2000 Compatible Connection Cable GST15i5 for 5-pole output connector see 6SACP5J516B.2000 Compatible Connection Coupling GST18i3 for 3-pole output connector see 6SAKP3J316BS01 Compatible Connection Coupling GST15i5 for 5-pole output connector see 6SAKP5J516BS01 Compatible Direct Connector I, slot 8 see 099DC084040N08 Compatible Direct Connector I / B, Slot 8 / 10 see 099DC084045N10Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 watts

€0.00*
Tool Hook FX 17/57 - 24 for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black | ESD: ESD electrostatical discharging
Color:Rear mounting holder: Black Front locking holder: BlackDelivery Countries:WorldwideDescription:Ready to use tool hook, 360° turnable, for perforated metals up to 1.4 mm thick; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder ESD electrostatical discharging version: Plastic PA, carbon fibre reinforced Front locking holder ESD electrostatical discharging: Plastic PA, glass ball reinforced with carbon Wire: Stainless steel SS304 Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TH240NA4060S01 For round tubes D28 / D30 see 6TH2D283A4060ESDS01

€0.00*
Profile Connector 90° M45 / N45, Slot 8 (Set)
Set: Set 1
Delivery Countries:WorldwideDescription:To connect two aluminum profilesMaterial:SteelSet 1:1 profile connector 90° M45 / N45 1 screw M8 x 25Set 2:1 profile connector 90° M45 / N45 1 self-forming screw S8 x 25Surface:Zinc plated

€0.00*
Drill / Driver Holder FX D50 for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black | Fig.:
Color:Rear mounting holder: Black, gray Front locking adapter: Black, gray Drill / driver holder: Black, grayDelivery Countries:WorldwideDescription:Ready to use tool Drill / Driver Holder for a wide range of standard cordless screwdrivers, 360° turnable, for perforated metals up to 1.4 mm thick; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder black version: Plastic PA, carbon fibre reinforced Rear mounting holder gray version: Plastic PA, glass fibre reinforced Front locking adapter: Plastic PA, glass ball reinforced Drill / driver holder: Plastic PA, glass ball reinforced Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TM840NL12591S01 For round tubes D28 / D30 see 6TM8D283L12591S01

€0.00*
Grab Tray 105 x 130 x 50 for Profil Slot (Set)
Color: Black | ESD: - | Slot N (mm): 8
Color:Grab tray: Black, yellow, red, blue, green, gray Label window: TransparentDelivery Countries:WorldwideDescription:To provide hardware and small parts on sorting area for selective grabbing of smallest components; simple assembly by swiveling into the profile slot; the clearly visible label area enables secure part identificationMaterial:Grab tray standard version: Plastic PA, glass fiber reinforced Grab tray ESD electrostatical discharging version: Plastic PA, carbon fiber reinforced Label window: Plastic PC Label: Carton 250 g/m² Bumper: Plastic PU, ≈ 65-70 Shore ASet:1 grab tray, 1 label window, 1 label, 4 bumper, self-adhesiveSpecials:Other colors on request

€0.00*
Roll-in Double T-slot Nut for Automatic Connector I, Slot 8
A (mm): 26.4 | L (mm): 36.0 | M: M6 | Profile: I
Delivery Countries:WorldwideDescription:Roll-in double T-slot nutMaterial:SteelSpecials:Different lengths with multiple threads in different sizes available on requestSurface:Zinc plated

€0.00*
Cover Cap for Zinc Connection Angle I 40
Color: Gray ≈ RAL 7042 | Fig.:
Color:Black, grayDelivery Countries:WorldwideDescription:To cover the open side of the connection angleMaterial:Plastic PA, glass fiber reinforcedTip:Compatible Zinc Connection Angle I 40 see 093W407N08R

€0.00*
LED Lamp Module F Line 476 Dimmable, with Button, for Series Connection
Profile: I | Slot N (mm): 8
Color:Housing standard version: - End caps: Black Diffusing screen: Transparent Dimmer button standard version: BlueDelivery Countries:WorldwideDescription:LED Lamp with dimmer button for power and light supply at work stations On the backside with slot 8 for mounting on aluminum profiles Can be dimmed in series if the downstream LED Lamp for Series Connection is dimmableMaterial:Housing: Aluminum End caps: Plastic PA, carbon fibre reinforced Diffusing screen: Polycarbonate Dimmer button: Plastic ABS/PASpecials:Other lengths, other colors on requestSurface:Housing standard version: AnodizedTip:Compatible LED Lamp Module F Line 476 Dimmable, for Series Connection see 6SL0040RI.476 Compatible Power Strip Module F Line 264 4xEU see 6SBEU04I.264 Compatible Main Power Cable GST18i3 for 3-pole input connector see 6SAME4J316B.2000 Compatible Connection Cable GST18i3 for 3-pole output connector see 6SACP3J316B.2000 Compatible Connection Cable GST15i5 for 5-pole output connector see 6SACP5J516B.2000 Compatible Connection Coupling GST18i3 for 3-pole output connector see 6SAKP3J316BS01 Compatible Connection Coupling GST15i5 for 5-pole output connector see 6SAKP5J516BS01 Compatible Direct Connector I, slot 8 see 099DC084040N08 Compatible Direct Connector I / B, Slot 8 / 10 see 099DC084045N10Tip 2:Please note: Chaining of max. 6 modules (LED lamps / power strips), cable length max. 15 m for main power cable, connection cables and modules Connected load max. 3500 watts

€0.00*
Tool Hook FX 24/16 - 12 for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black | ESD: ESD electrostatical discharging
Color:Rear mounting holder: Black Front locking holder: BlackDelivery Countries:WorldwideDescription:Ready to use tool hook, 360° turnable, for perforated metals up to 1.4 mm thick; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder ESD electrostatical discharging version: Plastic PA, carbon fibre reinforced Front locking holder ESD electrostatical discharging: Plastic PA, glass ball reinforced with carbon Wire: Stainless steel SS304 Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TH240NA5020S01 For round tubes D28 / D30 see 6TH2D283A5020ESDS01

€0.00*
Clamp Profile Connector 30 (Set)
Profile: I | Slot N (mm): 6
Color:Clamp profile connector: Alu colorDelivery Countries:WorldwideDescription:To connect two aluminum profiles at right angles and to attach a frame element to a frame structure by means of a suitable mounting; the upper monting defines the position in the structure, by shifting the lower mouting afterwards the frame can be fixed and lockedMaterial:Clamp profile connector: Zinc die-cast Screws: SteelSet:1 clamp profile connector, 2 screws DIN EN ISO 7380 (DIN 34805) - M6 x 16Surface:Clamp profile connector: Powder coated Screws: Zinc platedTip:Compatible Mounting for Clamp Profile Connector 30 (Set) see 093XWWC301N06

€0.00*
Tool Hook FX 7/38 - 24 for Square Holes 9 x 9 (8.7 x 8.7)
Color: Black | ESD: ESD electrostatical discharging
Color:Rear mounting holder: Black Front locking holder: BlackDelivery Countries:WorldwideDescription:Ready to use tool hook, 360° turnable, for perforated metals up to 1.4 mm thick; To organize workstations, with labeling area for standard labelsMaterial:Rear mounting holder ESD electrostatical discharging version: Plastic PA, carbon fibre reinforced Front locking holder ESD electrostatical discharging: Plastic PA, glass ball reinforced with carbon Wire: Stainless steel SS304 Spring: Spring steel SS313 Screw: Steel Nut: SteelSpecials:Other colors on request, For other sheet metal thicknesses on requestSurface:Screw: Zinc plated Nut: Zinc platedTip:For profiles 40 / 45, slot 8 / 10 see 6TH240NA3040S01 For round tubes D28 / D30 see 6TH2D283A3040ESDS01

€0.00*
Double Bearing Unit 2 Rollers Centric Shaft Ø 14
Profile: I
Delivery Countries:WorldwideDescription:To build sliding carriages To linearly guide loads, steel roller with ball bearings runs directly on shaft Ø 14 mm Completely pre-assembled from roller profile I slot 8Material:Roller: Steel Screws: Steel Washers: Steel Tension pins: Steel Profile: AluminumSurface:Roller: Zinc plated Screws: Zinc plated Washers: Zinc plated Tension pins: Zinc plated Profile: AnodizedTip:Compatible Wiper and Lubricator Ø 14 for Roller Profile I Slot 8 (Set) see 091381S01

€0.00*

CATALOG ENGINEERING COMPONENTS
