Productos

Países de Entrega:En todo el mundoDescription:To connect two aluminum profilesMaterial:AceroSuperficie:Galvanizado

Países de Entrega:En todo el mundoDescription:End-to-end connection of an aluminum profile with a mitre cut (cut γ = 45° - 90°) to another aluminum profile; before the application a hole with Ø 8.2 mm lateral must be drilled; with T-slot nut and threaded pin with AF 4Material:Galvanizado / lisoSuperficie:Galvanizado

Países de Entrega:En todo el mundoDescription:End-to-end connection of two aluminum profiles with a mitre cut (cut each γ = 60° - 90°); before the application a hole with Ø 8.2 mm in a distance of 34 mm of the profile end must be drilled; with T-slot nut and threaded pin with AF 4Material:AceroSuperficie:Galvanizado

Color:Cover cap: Gray ≈ RAL 7042Países de Entrega:En todo el mundoDescription:End-to-end connection of an aluminum profile with a mitre cut (cut γ = 30° - 90°) to another aluminum profile; before the application each a hole with Ø 14.2 mm lateral and Ø 9.0 mm frontal must be drilled; with T-slot nut and cover capMaterial:Connector and T-slot nut: Steel Cover caps: Plastic PPSurface:Connector and T-slot nut: Zinc plated

Color:Boards: White Wheel body: Gray ≈ RAL 7001 Tread: Gray ≈ RAL 7031Países de Entrega:En todo el mundoDescription:Flexible applicable cube, four-sided enamel coating for writing on, dry wipeable, magnetic, resistant enamelled surface, durable to mechanical and chemical influences; Space saving due to square base; Equipped with four swivel casters for moving, two of them incl. system brakes for securing against unintended movement; Profile frame 40 x 40 mm, without slot on the front side, entirely preassembledMaterial:Boards: MDF, steel Profile frame: Aluminum Wheel body: Plastic PP Tread: Plastic TPESpecials:Swivel casters as ESD electrostatically discharging version on requestSurface:Boards: Enamelled Profile frame: Anodized

Color:Monitor bracket: Black Articulation piece: Gray Centering piece: PlainPaíses de Entrega:En todo el mundoDescription:To fix flat screens to aluminum profile structures, VESA MIS-D 75/100 compatible, can be adjusted horizontally and vertically for optimum visibilityMaterial:Monitor bracket: Plastic PA, glass fiber reinforced Articulation piece: Plastic PA, glass fiber reinforced Centering piece: Plastic PA, glass fibre reinforced Mounting material: SteelEspeciales:Otros colores, otros tamaños bajo pedidoSurface:Mounting material: Zinc platedTip:Compatible Adapter Plate see 061SAP40H

Color:Monitor mounting plate: Black Pivot joint: Alu colored Locking lever: BlackPaíses de Entrega:En todo el mundoDescription:To fix flat screens to aluminum profile structures, VESA MIS-D 75/100 compatible, can be adjusted horizontally or vertically for optimum visibility, can be fixed with KIPP locking lever at any angle; with separate locating pins for slot 8 and slot 10Material:Monitor mounting plate: Plastic PA, glas fiber reinforced Pivot joint: Zinc die-cast KIPP locking lever: Plastic PA, glas fiber reinforcedSet 1:1 monitor mounting plate 1 assembly set for monitor: 4 cylinder head screws M4 x 12, 4 washers 1 pivot joint 40 with locking lever 1 assembly set for profile: 1 screw M8 x 25 (frontal), 1 screw M8 x 16 (lateral), 2 locating pinsSet 2:1 monitor mounting plate 1 assembly set for monitor: 4 cylinder head screws M4 x 12, 4 washers 1 pivot joint 45 with locking lever 1 assembly set for profile: 1 screw M8 x 25 (frontal), 1 screw M8 x 16 (lateral), 2 locating pins 1 cutting bush for the reduction of the Ø 10.2 mm core hole to thread size M8Especiales:Otros colores bajo pedidoSurface:Pivot joint: LaqueredTip:Cutting bush for the reduction of the Ø 10.2 mm core hole to thread size M8 see 09308801

Color:Monitor mounting plate: BlackPaíses de Entrega:En todo el mundoDescription:To fix flat screens to aluminum profile structures, VESA MIS-D 75/100 compatible; with separate locating pins for slot 8 and slot 10Material:Monitor mounting plate: Plastic PA, glass fiber reinforcedSet:1 monitor mounting plate 1 assembly set for monitor: 4 cylinder head screws M4x12, 4 washers assembly set for profile: M8x25 frontal and M8x16 slot side, 2 centering piecesEspeciales:Otros colores bajo pedidoTip:Cutting bush for the reduction of the Ø 10.2 mm core hole to thread size M8 see 09308801

Color:Mounting plate VESA, removable: Alu color / black Monitor mount: Alu color Cable management cover: Black Bearing shims and bushes: Black Mounting flange: Alu color Mounting adapter: Alu colorPaíses de Entrega:En todo el mundoDescription:For removable mounting of monitors with 2 - 10 kg or 8 - 20 kg, mounting plate VESA MIS-D 75/100 compatible; Adjustable viewing angle and height, screen rotatable by 90°; 360° mounting flange for horizontal and vertical attachment with mounting adapterMaterial:Mounting plate VESA, removable: Steel / Plastic Monitor mount: Die-cast aluminum Cable management cover: Plastic Bearing shims and bushes: Plastic Mounting flange: Die-cast aluminum Mounting adapter: Die-cast aluminum Screws: SteelSet:1 mounting plate VESA with 4 screws – M4 × 12, Phillips 1 monitor support 4-axis with cable management cover 1 mounting flange 1 mounting screw DIN 6912 – M8 × 25 1 mounting adapter 2 mounting screws DIN 6912 – M8 × 16 1 hexagon key, AF 3 1 hexagon key, AF 4Surface:Mounting plate VESA, removable: Lacquered Monitor mount: Lacquered Mounting flange: Lacquered Mounting adapter: Lacquered Screws: Zinc plated

Color:Mounting plate VESA, removable: Alu color / black Monitor mount: Alu color Cable management cover: Black Bearing shims and bushes: Black Mounting flange: Alu color Mounting adapter: Alu colorPaíses de Entrega:En todo el mundoDescription:For removable mounting of monitors with 2 - 10 kg or 8 - 20 kg, mounting plate VESA MIS-D 75/100 compatible; Adjustable viewing angle and height, screen rotatable by 90°; 360° mounting flange for horizontal and vertical attachment with mounting adapterMaterial:Mounting plate VESA, removable: Steel / Plastic Monitor mount: Die-cast aluminum Cable management cover: Plastic Bearing shims and bushes: Plastic Mounting flange: Die-cast aluminum Mounting adapter: Die-cast aluminum Screws: SteelSet:1 mounting plate VESA with 4 screws – M4 × 12, Phillips 1 monitor support 5-axis with cable management cover 1 mounting flange 1 mounting screw DIN 6912 – M8 × 25 1 mounting adapter 2 mounting screws DIN 6912 – M8 × 16 1 hexagon key, AF 3 1 hexagon key, AF 4Surface:Mounting plate VESA, removable: Lacquered Monitor mount: Lacquered Mounting flange: Lacquered Mounting adapter: Lacquered Screws: Zinc plated

Color:Monitor suspension arm: Gray Cable management cover: Gray Mounting flange: Alu colorPaíses de Entrega:En todo el mundoDescription:For mounting of heavy monitors with 6 - 12 kg, mounting plate VESA MIS-D 75/100 compatible, adjustable viewing angle and height; 360° mounting flange can be attached lateral or transverse to the profileMaterial:Monitor suspension arm: Steel / aluminum / plastic Cable management cover: Plastic Mounting flange: Aluminum die-cast Screws: SteelSet:1 monitor suspension arm incl. cable management cover 1 mounting flange incl. bolt and cover cap 2 screws DIN EN ISO 4762 (DIN 912) - M8 x 30 (for T-slot nut) 2 centering plates - slot 8 2 centering plates - slot 10 2 anti-loss washers for screws M8 2 T-slot nuts - slot 8 - M8 2 T-slot nuts - slot 10 - M8 1 connecting ring 1 washer 4 screws DIN 799 - M4 x 16Surface:Monitor suspension arm: Lacquered Mounting flange: Lacquered Screws: Zinc plated

Color:Monitor Work Station: Gray Cable management cover: Gray Mounting flange: Alu colorPaíses de Entrega:En todo el mundoDescription:For mounting of monitors with 2 - 8 kg, mounting plate VESA MIS-D 75/100 compatible, adjustable viewing angle and height; Fold-up holder with wrist rest for keyboard up to 2.5 kg, incl. left or right pull-out shelf for mouse, as well as holders for hand scanner and mouse; 360° mounting flange can be attached lateral, transverse, or on the face of the profile, if attached on the front face, the core hole of the respective profile must be M8 threadedMaterial:Monitor Work Station: Steel / aluminum / plastic Cable management cover: Plastic Mounting flange: Aluminum die-cast Screws: SteelSet:1 monitor work station incl. keyboard holder and cable management cover 1 mounting flange incl. bolt and cover cap 2 screws DIN EN ISO 4762 (DIN 912) - M8 x 45 (for T-slot nut) 2 screws DIN EN ISO 4762 (DIN 912) - M8 x 50 (for core hole) 2 washers 8-FSt 2 centering plates - slot 8 2 centering plats - slot 10 2 T-slot nuts - slot 8 - M8 2 T-slot nuts - slot 10 - M8Surface:Monitor Work Station: Powder coated Mounting flange: Powder coated Screws: Zinc plated

Países de Entrega:En todo el mundoDescription:For mounting diagonal struts to support posts in the upper slot of FIFO monorail rails 40Material:AluminioSet:6 angle connectors 45° 30 x 30, 4 screws DIN EN ISO 4762 (DIN 912) - M8 x 12, 4 T-slot nut- M8, 4 self-tapping screws - S8 x 25, 2 screws DIN EN ISO 4762 (DIN 912) - M8 x 14, 2 hexagon nuts DIN EN ISO 4035 (DIN 439) - M8Tip:Compatible FIFO Monorail Rail see 02082PO.1200

Países de Entrega:En todo el mundoDescription:To mount posts in the upper slot of FIFO monorail rail 40Material:AluminioSet:2 angle connector 45° 30 x 30, 2 screw DIN EN ISO 4762 (DIN 912) - M8 x 12, 2 T-slot nuts - M8, 2 self-tapping screw - S8 x 25Tip:Compatible FIFO Monorail Rail see 02082PO.1200

Color:NegroPaíses de Entrega:En todo el mundoDescription:To securely fix the trapezoid leveling foot to the floor - can be mounted afterwardMaterial:Zinc fundido a presiónSuperficie:Polvo cubiertoTip:Compatible Trapezoid Base see 098DI060ZS and 098AI060ZS

Países de Entrega:En todo el mundoDescription:To attach frame elements to a frame structureby means of clamp profile connectors; completely preassembled, for lateral insertion into the profile slot, fixation by means of a nut; the upper monting defines the position in the structure, by shifting the lower mouting afterwards the frame can be fixed and locked; 12 mm gap between frame and structure, dimensional tolerances of +/- 3 mm can be compensatedMaterial:T-slot nut: Steel Shim: Steel Nut: Steel Screw: Steel Ball: Stainless steelSet:Mounting, completely preassembled: 1 T-slot nut - slot 6 - M5, 1 shim DIN EN ISO 7093 (DIN 9021) - 5.3, 1 nut DIN EN ISO 4032 (DIN 934) - M5, 1 screw DIN 7984 - M5 x 30, 1 ball Ø 4Surface:T-slot nut: Zinc plated Shim: Zinc plated Nut: Zinc plated Screw: Zinc plated Ball: PlainTip:Compatible Clamp Profile Connector 30 (Set) see 093WWC301N06S01

Países de Entrega:En todo el mundoDescription:To attach frame elements to a frame structureby means of clamp profile connectors; completely preassembled, for lateral insertion into the profile slot, fixation by means of a nut; the upper monting defines the position in the structure, by shifting the lower mouting afterwards the frame can be fixed and locked; 12 mm gap between frame and structure, dimensional tolerances of +/- 3 mm can be compensatedMaterial:T-slot nut: Steel Shim: Steel Nut: Steel Screw: Steel Ball: Stainless steelSet:Mounting, completely preassembled: 1 T-slot nut - slot 8 - M6, 1 shim DIN EN ISO 7093 (DIN 9021) - 6.4, 1 nut DIN EN ISO 4032 (DIN 934) - M6, 1 screw DIN 7984 - M6 x 30, 1 ball Ø 4Surface:T-slot nut: Zinc plated Shim: Zinc plated Nut: Zinc plated Screw: Zinc plated Ball: PlainTip:Compatible Clamp Profile Connector 40 (Set) see 093WWC401N08S01

Países de Entrega:En todo el mundoDescription:To connect a tubular frame profile with Ø 28 mm outer diameter with a slot 10 aluminum profile; adjustable by slotted holesMaterial:AceroSet:1 mounting bracket, 1 self-tapping screw S8 x 25 - hexalobular Socket T40, 2 hammer head screws - Nut 10 - M8 x 20, 2 flange nuts M8Superficie:Galvanizado

Assembly Set:6 self-drilling screws DIN EN ISO 15481 (DIN 7504) - 3.9 x 16Países de Entrega:En todo el mundoDescription:To mount and support an AL roller track profile on a crossing tubular frame profilewith Ø 28 mm outer diameterMaterial:AceroEspeciales:Otras superficies, otros colores bajo pedidoSuperficie:Galvanizado

Países de Entrega:En todo el mundoDescription:To support an roller track AL or a aluminum profile slot 8 on a crossing tubular frame profile with Ø 30 mm outer diameterMaterial:AceroSet:1 mounting bracket, 2 T-slot nuts - slot 8 - M6, 2 screws DIN EN ISO 4762 (DIN 912) - M6 x 16Superficie:Galvanizado

Assembly Set:2 self-drilling screws DIN EN ISO 15481 (DIN 7504) - 3.9 x 16Países de Entrega:En todo el mundoDescription:To mount and support an roller track XST or a guiding rail XST central on a crossing tubular frame profile with Ø 28 mm outer diameterMaterial:AceroEspeciales:Otras superficies, otros colores bajo pedidoSuperficie:Galvanizado

PFA_AssemblySet:4 tornillos autoperforantes DIN 7504 Forma N - 3,9 x 16Países de Entrega:En todo el mundoDescription:To mount and support an roller track XST or a guiding rail XST central on a crossing tubular frame profile with Ø 30 mm outer diameterMaterial:AceroEspeciales:Otras superficies, otros colores bajo pedidoSuperficie:Galvanizado

Color:Mounting clamp: BlackPaíses de Entrega:En todo el mundoDescription:To laterally connect a tubular frame profilewith Ø 28 mm outer diameter to an aluminum profile, hole spacing compatible with Ergoswiss® lift cylindersMaterial:Connector: Zinc die-cast Assembly set: SteelSet:2 components for mounting clamp D28, 2 screws DIN EN ISO 4762 (DIN 912) - M5 x 16, 2 screws DIN EN ISO 4762 (DIN 912) - M5 x 10, 2 nuts DIN EN ISO 4032 (DIN 934) - M5Surface:Mounting clamp: Powder coated Assembly set: Zinc plated

Color:Mounting clamp: Gray Spacer: GrayPaíses de Entrega:En todo el mundoDescription:To attach panels universally to tubes and tubular frame profiles with Ø 30 mm outer diameter; including spacer to position panels over outer tubular frame connectors D30Material:Mounting clamp: Plastic PA Spacer: Plastic PA Assembly set: SteelSet:1 mounting clamp 1 spacer 1 square nut DIN 557 - M5 1 self-tapping screw SF4 x 12Superficie:Conjunto de montaje: Galvanizado
