Pivot Feet
Anti-slip Plate for Heavy-duty Pivot Feet
€0.00*
D (mm):
174
|
d (mm):
17.0
|
for Base:
175
Color:BlackDelivery Countries:WorldwideDescription:Prevents movement of leveling feet on slippery surfaces and absorbs some vibrationMaterial:Thermoplastic elastomer, ≈ 70 Shore ASpecials:ESD electrostatical discharging on requestZolltarifnummer:40169997900
Anti-slip Plate for Pivot Feet
€0.00*
D (mm):
49
|
Fig.:
①
|
Version:
-
|
for Base:
60
Color:BlackDelivery Countries:WorldwideDescription:Prevents movement of leveling feet on slippery surfaces and absorbs some vibrationMaterial:Thermoplastic elastomer, ≈ 70 Shore ASpecials:ESD electrostatical discharging on requestTip:* Also for bases with bolt down holesZolltarifnummer:40169997900
Base PA BDH for Heavy-duty Pivot Feet
€0.00*
Base:
125
|
D (mm):
125
|
F (mm):
57.5
|
Fmax (N):
17650
|
H (mm):
44
|
LK (mm):
96
|
Version:
without anti-slip plate
|
d (mm):
13.4
|
h (mm):
24
Color:BlackDelivery Countries:WorldwideDescription:A heavy-duty leveling foot for strong positioning on slightly uneven floorsMaterial:Plastic PA, glass ball reinforcedSpecials:ESD electrostatical discharging, other sizes, other colors, bolt-on or glued anti-slip plate on request; as factory assembled leveling foot on requestTip:Compatible Threaded Rod see 098AM12066M, Compatible Nut see 4DIN439BM5M et sq., Compatible Anti-slip Plate 098AG125BZolltarifnummer:39269097900
Base PA BDH for Pivot Feet
€0.00*
Base:
100
|
D (mm):
99
|
Fmax (N):
11770
|
LK (mm):
74
|
Version:
without anti-slip plate
Color:BlackDelivery Countries:WorldwideDescription:A leveling foot which can be fixed to the floorMaterial:Plastic PA, glass ball reinforcedSpecials:ESD electrostatical discharging, other sizes, other colors, bolt-on or glued anti-slip plate on request; as factory assembled leveling foot on requestTip:Compatible Threaded Rod see 098AM12066M, Compatible Nut see 4DIN439BM5M et sq., Compatible Anti-Slip Plate 098AG050; * Bolt-down holes closedZolltarifnummer:39269097900
Base PA for Pivot Feet
€0.00*
Base:
100
|
D (mm):
99
|
Fmax (N):
11770
|
Version:
with anti-slip plate
Color:BlackDelivery Countries:WorldwideDescription:A leveling foot for strong positioning on slightly uneven floorsMaterial:Plastic PA, glass ball reinforcedSpecials:ESD electrostatical discharging, other sizes, other colors, bolt-on or glued anti-slip plate on request; as factory assembled leveling foot on requestTip:Compatible Threaded Rod see 098AM12066M, Compatible Nut see 4DIN439BM5M et sq., Compatible Anti-Slip Plate 098AG050Zolltarifnummer:39269097900
Base SS BDH for Pivot Feet
€0.00*
Base:
120
|
D (mm):
119
|
Fmax (N):
34300
|
LK (mm):
94
|
Version:
with anti-slip plate
Delivery Countries:WorldwideDescription:A leveling foot which can be fixed to the floorMaterial:Stainless steel SS303Specials:Other sizes, glued anti-slip plate on request; As factory assembled leveling foot on requestSurface:PlainTip:Compatible Threaded Rod see 098AM12066E, Compatible Nut see 4DIN439BM5E et sq., Compatible Anti-Slip Plate 098AG050Zolltarifnummer:73269098900
Base SS for Pivot Feet
€0.00*
Base:
120
|
D (mm):
119
|
Fmax (N):
44100
|
Version:
without anti-slip plate
Delivery Countries:WorldwideDescription:A leveling foot for strong positioning on slightly uneven floorsMaterial:Stainless steel SS303Specials:Other sizes, glued anti-slip plate on request; As factory assembled leveling foot on requestSurface:PlainTip:Compatible Threaded Rod see 098AM12066E, Compatible Nut see 4DIN439BM5E et sq., Compatible Anti-Slip Plate 098AG050Zolltarifnummer:73269098900
Base ZN BDH for Pivot Feet
€0.00*
Base:
60
|
D (mm):
59
|
Fmax (N):
29400
|
LK (mm):
40
|
Version:
without anti-slip plate
Color:BlackDelivery Countries:WorldwideDescription:A leveling foot which can be fixed to the floorMaterial:Zinc die-castSpecials:Other surfaces, other sizes, other colors, bolt-on or glued anti-slip plate on request; As factory assembled leveling foot on requestSurface:Powder coatedTip:Compatible Threaded Rod see 098AM12066M, Compatible Nut see 4DIN439BM5M et sq., Compatible Anti-Slip Plate 098AG050Zolltarifnummer:79070000900
Base ZN for Pivot Feet
€0.00*
Base:
80
|
D (mm):
79
|
Fmax (N):
34300
|
Version:
with anti-slip plate
Color:BlackDelivery Countries:WorldwideDescription:A leveling foot for strong positioning on slightly uneven floorsMaterial:Zinc die-castSpecials:Other surfaces, other sizes, other colors, bolt-on or glued anti-slip plate on request; As factory assembled leveling foot on requestSurface:Powder coatedTip:Compatible Threaded Rod see 098AM12066M, Compatible Nut see 4DIN439BM5M et sq., Compatible Anti-Slip Plate 098AG050Zolltarifnummer:79070000900
Extended Base 80 ZN for Pivot Feet
€0.00*
Base:
80
|
Fmax (N):
34300
|
Version:
without anti-slip plate
Color:BlackDelivery Countries:WorldwideDescription:Extended leveling foot which can be fixed to the floorMaterial:Zinc die-castSpecials:Other surfaces, other sizes, other colors, screwed or glued anti-slip plate on request; As factory assembled leveling foot on requestSurface:Powder coatedTip:Compatible Threaded Rod see 098AM12066M, Compatible Nut see 4DIN439BM5M et sq., Compatible Anti-Slip Plate 098AG050Zolltarifnummer:79070000900
Floor Mounting for Base of Trapezoid Foot
€0.00*
A (mm):
70.0
|
B (mm):
76.5
|
C (mm):
48.0
|
D (mm):
14.0
|
H (mm):
20.0
|
L (mm):
150.0
|
Profile:
I
|
for Base:
80
Color:BlackDelivery Countries:WorldwideDescription:To securely fix the trapezoid leveling foot to the floor - can be mounted afterwardMaterial:Zinc die-castSurface:Powder coatedTip:Compatible Trapezoid Base see 098DI060ZS and 098AI060ZSZolltarifnummer:79070000900
Threaded Rod SS UNC for Pivot Feet
€0.00*
Fmax (N):
35400
|
Material:
Stainless steel
|
SW (mm):
22 (7/8")
|
UNC x L (in):
1-8 UNC x 4"
Delivery Countries:WorldwideDescription:Threaded rod for pivot leveling feetMaterial:Stainless steel SS303Specials:Other lengths and sizes on requestSurface:PlainTip:*2. For pivot feet: Assembly set 098XAES03 included *2. For heavy-duty pivot feet: Assembly set 098XAUE includedZolltarifnummer:73181575900
Threaded Rod ST UNC for Pivot Feet
€0.00*
Fmax (N):
14200
|
Material:
Steel
|
SW (mm):
22 (7/8")
|
UNC x L (in):
-
Delivery Countries:WorldwideDescription:Threaded rod for pivot leveling feetMaterial:SteelSpecials:Other lengths and sizes on requestSurface:Zinc platedTip:*2. For pivot feet: Assembly set 098XAMS03 included * 2. For heavy-duty pivot feet: Assembly set 098XAUM includedZolltarifnummer:73181582900
Trapezoid Base for Pivot Feet, Black
€0.00*
Base:
60
|
D (mm):
59
|
F (mm):
31.0
|
Fmax (N):
24500
|
H (mm):
18
|
Version:
without anti-slip plate
Color:BlackDelivery Countries:WorldwideDescription:A leveling foot for strong positioning on slightly uneven floorsMaterial:Zinc die-castSpecials:Other sizes, glued anti-slip plate on request; As factory assembled leveling foot on requestSurface:Powder coatedTip:Compatible Threaded Rod see 098AM12066M, Compatible Nut see 4DIN439BM5M et sq., Compatible Anti-Slip Plate 098AG050Zolltarifnummer:79070000900
Trapezoid Base for Pivot Feet, Gray
€0.00*
Base:
80
|
D (mm):
76
|
F (mm):
33.0
|
Fmax (N):
29400
|
H (mm):
20
Color:White aluminum ≈ RAL 9006Delivery Countries:WorldwideDescription:A leveling foot for strong positioning on slightly uneven floorsMaterial:Zinc die-castSpecials:Other sizes, glued anti-slip plate on request; As factory assembled leveling foot on requestSurface:Powder coatedTip:Compatible Threaded Rod see 098AM12066M, Compatible Nut see 4DIN439BM5M et sq., Compatible Anti-Slip Plate 098AG050Zolltarifnummer:79070000900
